Notes:

Dimensions:

FMU: 73mm x 46mm x 18.5mm

PMU: 88mm x 44mm x 15.5mm

• Weight:FMU: 65g

• PMU: 80g

• Power Supply Range: 16V – 100V (4S – 24S)

• Operating Temperature: -25ºC to 60ºC

• Hovering Accuracy:

• Dual GNSS: Horizontal ±1m; Vertical ±0.5m

• RTK: Horizontal ±0.1m; Vertical ±0.1m

• Wind Resistance Rating: ≤6 levels

• Maximum Lifting Speed: ±3m/s

• Maximum Horizontal Speed: 10m/s

• Maximum Attitude Angle: 18°

• Course Pressure Line Accuracy: ≤50cm

• Spraying System Interface: 4-way pump output, dual flow meter monitoring, dual level meter monitoring

• Type of Drone: Sprayers, Foggers, Seeders, Throwers, Strip-tillers

• Exclusive of GST
