Gimbal Stabilization

Notes:

• Yaw, Pitch, Roll Stabilization
• Controllable Pitch Angle: -135° to +45°
• Controllable Yaw Angle: -160° to +160°
• Roll Angle: -30° to +30°
• Angular Vibration Range: ± 0.01°

Camera

Notes:

• Lens: Fixed focal length, 6X digital zoom
• Image Sensor: Sony 1/1.7-inch, 8 MP effective resolution
• Aperture: F2.8
• Field of View (FOV): Diagonal 93°, Horizontal 81°
• Video Recording Resolutions:
• 4K (4096 × 2160) @ 25 fps
• 2K (2560 × 1440) @ 30 fps
• 1080p (1920 × 1080) @ 30 fps
• 720p (1280 × 720) @ 30 fps
• Video Storage Bitrate (H.265 Codec):
• 4K/2K: 20 Mbps
• 1080p/720p: 15 Mbps
• Image Format: JPG
• Video Format: MP4
• Supported MicroSD Cards: Class10, max 512GB
• Still Photography Mode: Single-shot
• White Balance: Auto

Connectivity

Notes:

• Video Output Ports: Ethernet, CVBS, Micro-HDMI
• Control Signal Input Ports: S. Bus, UART, Ethernet UDP/TCP
• Control Signal Output Port: S. Bus

Power and Performance

Notes:

• Working Voltage: 11 to 25.2 V (3S to 6S)
• Note: Early manufacturing lots before June 2023 may not support 25.2V.
• Power Consumption: Average 5W, Peak 12W
• Waterproof Level: IP4X
• Working Temperature: -10°C to 50°C

Dimensions and Weight

Notes:

• Dimensions: 55 x 55 x 70 mm
• Weight: 95 g
