Product parameters

Supported Multi-rotor Types:

Quadcopter (+, X)

Hexacopter (+, X, IY and YI coaxial twins)

Octocopter (+ type, X type, V type)

Supported ESC Type: 490HZ or less PWM ESC

Maximum Output Channel: 8 channels

Recommended remote control type

Supported Receiver Types: PPM, S-BUS receiver

Support Expansion Equipment: K-BOX, IOT, RTK, obstacle avoidance radar, terrain radar, integrated remote control, FPV camera, flow meter, level gauge

Working Voltage: 2-12S

Power Consumption: less than 5W

Working Environment Temperature: -10~60°C

Storage Environment Temperature: -25~60°C

Earthquake Resistance Rating: Flight characteristics

Hovering Accuracy: horizontal direction ±1.5 m; vertical direction ±0.5 m

Maximum Tilt Angle: 30°

Maximum Yaw Speed: 150°/ sec

SBUS Receiver Maximum Vertical Speed: 6 m / s

Wind Resistance: continuous wind: 4

Gust: Level 5

Flight Mode And Function:

Attitude mode, GPS mode, AB operation, route operation, one-button return loss control, out of control continue operation, low voltage protection, fence function, log storage function, landing lock function, no-fly zone function, vibration protection function, star protection Function, active noise reduction function, motor sequence detection function, direction detection function, dual pump mode, drug break protection function, precision spray, water pump switch control, water pump linkage control

Hardware specification

Total Net Weight: 321g

FC: 87g

PMU: 41g

PMU2 (ups): 44g

Size

FC: 72.6mm × 48.0mm × 22.8mm

PMU: 53.4mm × 34.4mmx14.5mm

PMU2 (ups): 53.4mm × 34.4mmx14.5mm

GPS: 62*14.3mm

LED: 24*24*8mm
