Description:

Mechanical

Notes:

• Dimensions56.4 x 45.3 x 14.6 mm
• Weight35 g
• Operating tº-20…+65 ºC

Electrical

Notes:

• Input voltage on USB and JST GH4.75 - 5.5 V
• Antenna DC bias3.3 V
• Avg. consumption @5V200 mA Positioning
• Static horizontal4 mm + 0.5 ppm
• Static vertical8 mm + 1 ppm
• Kinematic horizontal7 mm + 1 ppm
• Kinematic vertical14 mm + 1 ppm

Data

Notes:

• CorrectionsNTRIP, VRS, RTCM3
• Position outputNMEA, LLH/XYZ
• Data loggingRINEX with events with update rate up to 20 Hz* *coming with a software update, up to 10 Hz now
• Internal storage16 GB

GNSS

Notes:

• Signal trackedGPS/QZSS L1C/A, L2C GLONASS L1OF, L2OF BeiDou B1I, B2I Galileo E1-B/C, E5b
• Number of channels184
• Update rates20 Hz* GPS / 10 Hz GNSS *coming with a software update, up to 10 Hz now
• IMU9DOF
